Ürün Kodu: ABxxxMRERA
Gelişmiş Fırçasız DC Motor Teknolojisi Sayesinde Fısıltı Sessizliğinde Kesintisiz Performans!
Her Yöne Ayrı Ayarlanabilen Bağımsız Kontrol Sistemi İle Mekanın Her Köşesinde Kişiselleştirilmiş Kusursuz Konfor!
Yenilikçi Ses Yalıtım Teknolojisi İle Gürültü İletimini Keserek 3 dB(A) Daha Sessiz, Çok Daha Huzurlu Bir Yaşam Alanı!
Şıklığı Tamamlayan Gizli LCD Ekran İle Minimalist ve Zarif Görünüm!
TBA – WBA
| Model/Indoor unit | Model | AB072MRERA | AB092MRERA | AB122MRERA | AB162MRERA | AB182MRERA | AB242MRERA | AB282MRERA | AB302MRERA | AB382MRERA | AB482MRERA | AB602MRERA | |
| Capacity | Cooling | kBtu/h | 7.5 | 9.5 | 12.3 | 15.3 | 19.1 | 24.2 | 27.3 | 30.7 | 38.2 | 47.7 | 54.6 |
| kW | 2.2 | 2.8 | 3.6 | 4.5 | 5.6 | 7.1 | 8 | 9 | 11.2 | 14 | 16 | ||
| Heating | Btu/h | 8.5 | 10.9 | 13.6 | 17.1 | 21.5 | 27.3 | 30.7 | 34.1 | 42.6 | 54.6 | 61.2 | |
| kW | 2.5 | 3.2 | 4 | 5 | 6.3 | 8 | 9 | 10 | 12.5 | 16 | 18 | ||
| Electrical Parameters | Power supply | Ph/V/Hz | 1/220~230/50/60 | 1/220~230/50/60 | 1/220~230/50/60 | 1/220~230/50/60 | 1/220~230/50/60 | 1/220~230/50/60 | 1/220~230/50/60 | 1/220~230/50/60 | 1/220~230/50/60 | 1/220~230/50/60 | 1/220~230/50/60 |
| Performance | Air flow (H) | m³/h | 1000/810/620 | 1000/810/620 | 1000/810/620 | 1000/810/620 | 1000/810/620 | 1380/1190/1000 | 1380/1190/1000 | 2050/1860/1670 | 2050/1860/1670 | 2100/1910/1720 | 2100/1910/1720 |
| Sound pressure level(H/M/L) | dB(A) | 30/27/25 | 30/27/25 | 30/27/25 | 32/29/27 | 33/30/29 | 35/34/31 | 37/35/31 | 37/35/31 | 37/35/31 | 44/40/36 | 44/40/36 | |
| Installation | External dimensions(W/D/H) | mm | 840/840/180 | 840/840/180 | 840/840/180 | 840/840/180 | 840/840/180 | 840/840/204 | 840/840/204 | 840/840/246 | 840/840/246 | 840/840/288 | 840/840/288 |
| Shipping dimensions(W/D/H) | mm | 983/983/268 | 983/983/268 | 983/983/268 | 983/983/268 | 983/983/268 | 983/983/290 | 983/983/290 | 983/983/331 | 983/983/331 | 983/983/373 | 983/983/373 | |
| Net/Shipping weight | kg | 25/28 | 25/28 | 25/28 | 25/28 | 25/28 | 27/30 | 27/30 | 31/36 | 31/36 | 33/38 | 33/38 | |
| Refrigerant liquid pipe | mm | 6.35 | 6.35 | 6.35 | 6.35 | 6.35 | 9.52 | 9.52 | 9.52 | 9.52 | 9.52 | 9.52 | |
| Refrigerant gas pipe | mm | 9.52 | 9.52 | 12.7 | 12.7 | 12.7 | 15.88 | 15.88 | 15.88 | 15.88 | 15.88 | 15.88 | |
| Panel | Model name | PB-950KB/PB-950KB(H) | |||||||||||
| External dimensions(W/D/H) | mm | 950/950/50 | 950/950/50 | 950/950/50 | 950/950/50 | 950/950/50 | 950/950/50 | 950/950/50 | 950/950/50 | 950/950/50 | 950/950/50 | 950/950/50 | |
| Shipping dimensions(W/D/H) | mm | 1013/1025/123 | 1013/1025/123 | 1013/1025/123 | 1013/1025/123 | 1013/1025/123 | 1013/1025/123 | 1013/1025/123 | 1013/1025/123 | 1013/1025/123 | 1013/1025/123 | 1013/1025/123 | |
| Net/Shipping weight | kg | 6.5/9 | 6.5/9 | 6.5/9 | 6.5/9 | 6.5/9 | 6.5/9 | 6.5/9 | 6.5/9 | 6.5/9 | 6.5/9 | 6.5/9 | |
| Controller | Wired(Optional) | / | HW-SA201ABK | HW-SA201ABK | HW-SA201ABK | HW-SA201ABK | HW-SA201ABK | HW-SA201ABK | HW-SA201ABK | HW-SA201ABK | HW-SA201ABK | HW-SA201ABK | HW-SA201ABK |
| / | YR-E17A | YR-E17A | YR-E17A | YR-E17A | YR-E17A | YR-E17A | YR-E17A | YR-E17A | YR-E17A | YR-E17A | YR-E17A | ||
| Infrared(Optional) | / | YR-HQS01 | YR-HQS01 | YR-HQS01 | YR-HQS01 | YR-HQS01 | YR-HQS01 | YR-HQS01 | YR-HQS01 | YR-HQS01 | YR-HQS01 | YR-HQS01 | |
| / | YR-HRS01 | YR-HRS01 | YR-HRS01 | YR-HRS01 | YR-HRS01 | YR-HRS01 | YR-HRS01 | YR-HRS01 | YR-HRS01 | YR-HRS01 | YR-HRS01 | ||
